Double Toggle Jaw Crusher

Author:liming   Post Date:2012-12-6

Double Toggle Jaw Crusher

Double Toggle Jaw Crusher Introduction:

The double toggle jaw crusher is the most widely used type of crusher has the advantages of large crushing ratio, product stone shape uniform, simple structure, easy maintenance. double toggle jaw crusher is divided into coarse and fine broken two, to achieve the maximum compressive strength of the 320Mpa the materials carried broken.

Double Toggle Jaw Crusher Main Structure:

Structure of the double toggle jaw crusher frame, eccentric shaft, big pulley, flywheel, moving jaw, side guard plate, toggle plate, toggle plate back seat, adjust gap screw, reset spring, fixed jaw plate and movable jaw plate., which brackets also play a role as insurance.

Double Toggle Jaw Crusher How to Select Manufacturers:

First look at the strength of manufacturers, reputation, size;

Second, to look at the the manufacturers product quality, technical level, the degree of maturity;

Again to the manufacturer's production site, the user's site is the most convincing;

Finally, be sure to shop around, carefully inspected, and choose carefully.

Double Toggle Jaw Crusher Working Principle:

Motor through the belt so that the rotation of the eccentric shaft, the up and down movement of the vertical rod that is, when the vertical link up, driven by two brackets gradually stretched flat bracket to force the movable jaw to the fixed jaw forward, crushing chamber (iecomposed of fixed jaw plate and moving jaw space) in the ore being squeezed, splitting, fold flexor and broken. Vertical link-down movement, toggle plate and movable jaw plate, by the force of the springs and tie rods to the back at the port of discharge increase, the ore is broken thus discharged. Visible double toggle jaw crusher is intermittently broken ore. The eccentric shaft of a turn each half cycle for crushing and subsequent half cycle for the row of ore. So it is compared with other continuous crushing machinery, power consumption greater mechanical efficiency is lower.

Double Toggle Jaw Crusher in China:

China is a big country, and could produce double toggle jaw crusher every year, a large number of quality product is produced and sold around the world. The quality of double toggle jaw crusher produced in China is guaranteed, and the price is relatively cheap. It is the best choice to buy double toggle jaw crusher in China. But choose to buy double toggle jaw crusher can not be blindly freeloaders, they should have chosen a large formal double toggle jaw crusher manufacturer. So to protect the interests of buyers, and can provide the necessary technical support and maintenance services.
