Grinding Mill Machine
Author:liming Post Date:2013-10-31
Grinding Mill Machine
Grinding Mill Machine Introduction:
Grinding mill machine is independently developed a new mechanical grinding equipment, its low energy consumption, set centrifugal crushing, impact crushing, squeezing crushed in an energy saving 40 to 50% higher than other types of mechanical grinder. The high fineness: with the grading system from Split, the product fineness ≥ 2500 mesh, feeding, feed size ≤ 50mm material only the a coarse broken equipment. Low abrasion, crushing part of the wearing parts the composite wear new material, long service life, pollution-free processing Mohs hardness ≤ 5 material.
Grinding Mill Machine Application:
Grinding mill machine is widely applicable to the barite, calcite, feldspar, talc, marble, limestone, dolomite, fluorite, lime, activated clay, activated carbon, bentonite, kaolin, cement, phosphate rock, gypsum, glassinsulation materials Mohs hardness of not more than 7 and humidity below 6% of non-flammable mineral, chemical, construction and other industries more than 300 kinds of materials for high fine powder processing.
Accessories Material:
The grinding mill machine fittings grinding roller and grinding ring. Which, roller and grinding ring two materials:
1, 65Mn: after using this material, the grinding roller and grinding ring, its durability is significantly improved. This product is characterized by high hardness, wear resistance, and magnetic. The product is mainly used for removal of iron powder processing areas. The product after normalizing heat treatment, the mechanical properties greatly improved, making the product not only good wear resistance and toughness greatly improve.
2, Mn13G2: Compared with 65Mn, roller and grinding ring using of the Mn13G2 material casting, durability has changed. This product castings after pouring water toughening treatment. Water toughening treatment after casting With high tensile strength, toughness, stone and non-magnetic. Roller and grinding ring more durable. Use of the process by the surface hardening, the deformation of the severe shock and strong pressure, and martensite is formed, thereby forming a high abrasion resistant surface layer, while the inner maintaining excellent toughness even wear to the thin, can also be withstand greater shock load.
Grinding Mill Machine Installation:
Install grinding mill machine run the site have not been installed, you should take good care of the exposed surfaces are coated with anti-rust grease, and avoid the sun and rain, to prevent the body rust water, To establish maintenance system. Plant and foundation should have enough height and installation location of the installed base size of the chart according to Raymond, Raymond should be based on high-standard cement and shall be buried reinforced before being placed foundation, and I buried conduit or cable trench. After pouring the cement foundation, there must be a 15-day maintenance period. Should be 2 to 3 tons with a lifting tool for Raymond installation maintenance. Raymond from the factory to use over six months, to host the central axis of the system, the transmission roller device, and analysis of oil pools should be cleaned inspection, cleaning checked respond to the various components add sufficient lubricant.
Grinding Mill Machine Advantages and Trends:
With the continuous development of the milling machinery industry, grinding mill machine as the the powder industry grinding equipment. High reliability, energy-saving, precision, automation is the inevitable trend of development.
Grinding mill machine production and R & D experience, in recent years, Raymond is widely used in the fields of metallurgy, building materials, chemical, mining minerals such as grinding materials processing, suitable for processing Mohs hardness of seven, humidity below 6% a variety of non-explosive minerals such as gypsum, talc, calcite, limestone, marble, feldspar, barite, dolomite, granite, kaolin, bentonite, medical stone, bauxite, iron oxide red, iron mine, such as, product fineness of 613 microns to 440 microns (0.613 mm -0.44 mm), through the analysis of machine and fan together, to meet the different requirements of users.
Experts believe that, grinding mill machine powder industry mainly to the high reliability, the development of energy-saving, accurate, automatic condition monitoring and automatic control direction. Using SCR power supply, AC variable speed, centralized grease lubrication, shock absorption, and other measures, and condition monitoring and microcomputer automatic control device. Which high reliability through mechanical principle of rationalization study reinforced grinding ring under the wear resistance of the gland, etc., to improve the machine in a continuous state bearing lubrication before. Automatic condition monitoring and automation control need increased Raymond inside the the high intelligent electronic control system, out of the automatic control materials, grinding, and quantitative. The operator need only in the operating room, the button control. Improve the precision grinding of materials needed to enhance the accuracy of the analysis machine.
Liming Grinding Mill Machine:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy grinding mill machine manufacturer capable of producing all types of grinding mill machine, good quality and reasonable prices. Liming Heavy Industry production of grinding mill machine is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized grinding mill machine is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of grinding mill machine, please contact us directly. We aim to provide you with the best grinding mill machine and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
