Pulverizer Mill Machine
Author:liming Post Date:2012-11-14
Pulverizer Mill Machine
Pulverizer Mill Machine Introduction:
Pulverizer mill machine is independently developed a new mechanical grinding equipment, its low energy consumption, set centrifugal crushing, impact crushing, squeezing crushed in an energy saving 40 to 50% higher than other types of mechanical grinder. The high fineness: with the grading system from Split, the product fineness ≥ 2500 mesh, feeding, feed size ≤ 50mm material only the a coarse broken equipment. Low abrasion, crushing part of the wearing parts the composite wear new material, long service life, pollution-free processing Mohs hardness ≤ 5 material.
Pulverizer Mill Machine Working Principle:
Large block of raw materials to the required feed size jaw crusher crushing machine materials transported to storage silos, and then by the electromagnetic vibrating feeder evenly sent to the host of grinding cavity, shovel bucket elevator knife and grinding roller with the transfer process, the material is scooped up throwing feeding grinding roller between the roller ring, the formation of the litter layer, the material between the roller and grinding ring grinding, and thus achieve pulverizing purpose. The powder after grinding by the fan airflow into the analysis machine for powder fineness requirements fine powder with the air flow through the pipe into the large cyclone collector, collected separately, then unloader discharge is the finished powder return air duct airflow from the upper end of the large cyclone collector inhalation blower. The powder will be undesirable leaves thrown to the outer wall and the air flow from the coarse sub due to the role of self-gravity into the grinding chamber for regrinding. The entire airflow system of the machine is closed loop, and is in the positive and negative pressure state where the circulating flow.
Pulverizer Mill Machine Accessories Material:
The Raymond Accessories grinding roller and grinding ring. Which, roller and grinding ring two materials:
1,65 Mn: after using this material, the grinding roller and grinding ring, its durability is significantly improved. This product is characterized by high hardness, wear resistance, and magnetic. The product is mainly used for removal of iron powder processing areas. The product after normalizing heat treatment, the mechanical properties greatly improved, making the product not only good wear resistance and toughness greatly improve.
2, Mn13G2: Compared with 65Mn, roller and grinding ring using of the Mn13G2 material casting, durability has changed. This product castings after pouring water toughening treatment. Water toughening treatment after casting With high tensile strength, toughness, stone and non-magnetic. Roller and grinding ring more durable. Use of the process by the surface hardening, the deformation of the severe shock and strong pressure, and martensite is formed, thereby forming a high abrasion resistant surface layer, while the inner maintaining excellent toughness even wear to the thin, can also be withstand greater shock load.
The Pulverizer Mill Machine Working Process:
Will need to crush the material uniformly continuous fed into the grinding chamber, scoop up material sent between the roller and grinding ring rotates, centrifugal force, grinding roller swings out, pressed on the grinding ring blade, because of the grinding rollers rolling the reach crushed purpose.
Material after grinding, grinding into the analysis with the blower circulating air separation, fine through coarse material Rockwell will re-grinding, qualified powder into the finished product cyclone powder collector with the flow discharged stone tube, that is for the finished product.
Materials in the grinding room was grinding some moisture, grinding heat, moisture evaporation, and the whole pipe interface is not tight, the outside air is inhaled, the circulation increased pressure to ensure that the mill work in the vacuum state , the increase in gas flow through the I wind tube into the dust collector, into the atmosphere after being purified.
Liming Pulverizer Mill Machine:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy pulverizer mill machine manufacturer capable of producing all types of pulverizer mill machine, good quality and reasonable prices. Liming Heavy Industry production of pulverizer mill machine is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized pulverizer mill machine is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of pulverizer mill machine, please contact us directly. We aim to provide you with the best pulverizer mill machine and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
