Grinding Mill Suppliers
Grinding Mill Introduction:
Grinding mill for barite, calcite, feldspar, talc, marble, limestone, ceramic, glass, Mohs hardness not more than seven, non-flammable and explosive mining humidity below 6%,280 kinds of materials in the stone industry, building materials, metallurgy and other industries powder processing, product size is in the range of 100-425 mesh arbitrary regulation.
Grinding Mill Work Process:
Will need to crush the material uniformly continuous fed into the grinding chamber, scoop up material sent between the roller and grinding ring rotates, centrifugal force, grinding roller swings out, pressed on the grinding ring blade, because of the grinding rollersrolling the reach crushed purpose.
Material after grinding, grinding into the analysis with the blower circulating air separation, fine through coarse material Rockwell will re-grinding, qualified powder into the finished product cyclone powder collector with the flow discharged stone tube, that is for the finished product.
Materials in the grinding room was grinding some moisture, grinding heat, moisture evaporation, and the whole pipe interface is not tight, the outside air is inhaled, the circulation increased pressure to ensure that the mill work in the vacuum state , the increase in gas flow through the I wind tube into the dust collector, into the atmosphere after being purified.
Accessories Material:
The grinding mill fittings grinding roller and grinding ring. Which, roller and grinding ring two materials:
1, 65Mn: after using this material, the grinding roller and grinding ring, its durability is significantly improved. This product is characterized by high hardness, wear resistance, and magnetic. The product is mainly used for removal of iron powder processing areas. The product after normalizing heat treatment, the mechanical properties greatly improved, making the product not only good wear resistance and toughness greatly improve.
2, Mn13G2: Compared with 65Mn, roller and grinding ring using of the Mn13G2 material casting, durability has changed. This product castings after pouring water toughening treatment. Water toughening treatment after casting With high tensile strength, toughness, stone and non-magnetic. Roller and grinding ring more durable. Use of the process by the surface hardening, the deformation of the severe shock and strong pressure, and martensite is formed, thereby forming a high abrasion resistant surface layer, while the inner maintaining excellent toughness even wear to the thin, can also be withstand greater shock load.
Grinding Mill Application Scope:
Grinding mill for barite, calcite, feldspar, talc, marble, limestone, ceramic, glass, Mohs hardness not more than seven, non-flammable and explosive mining humidity below 6%,280 kinds of materials in the stone industry, building materials, metallurgy and other industries powder processing, product size is in the range of 100-425 mesh arbitrary regulation.
Liming Grinding Mill Suppliers:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy grinding mill manufacturer capable of producing all types of grinding mill, good quality and reasonable prices. Liming Heavy Industry production of grinding mill is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized grinding mill is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of grinding mill suppliers, please contact us directly. We aim to provide you with the best grinding mill and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
