Rock Crusher Overview:
Various types of rock crusher broken principles and product particles of different sizes, is divided into many models. The rock crusher is widely used in mining, metallurgy, building materials, road, railway, water conservancy and stone industry and many other sectors. Commonly broken machinery jaw crusher plans, impact crusher plans, vertical impact crusher, hydraulic cone crusher, ring hammer crusher, hammer crusher, roll crusher, compound crusher, etc..
Jaw Crusher Plans:
The jaw crusher plans is mainly used for a variety of ores and bulk materials, medium-grained crushing, crushing compression strength not more than 320Mpa materials, sub-coarse and fine broken two kinds. Jaw Crusher Series product specification is complete, the feed particle size of 125mm ~ 750mm, the primary crushing preferred equipment. Jaw crusher (cracker) are widely used in mining, metallurgy, building materials, road, railway, water conservancy and stone and other industries.
The jaw crusher plans is squeezing and bending role of two jaw materials, rough broken or broken in various hardness materials broken machinery. Their broken bodies are composed of fixed jaw and movable jaw the when two jaw near the material is broken, when two jaw left less than a block of material discharge opening is discharged from the bottom. Its crushing action is carried out intermittently. This crusher due to simple structure, reliable and crushing hard materials are widely used in industrial sectors such as mineral processing, building materials, silicate and ceramic cone crusher, jaw crusher less investment finished sheet rock, low production costs. Compared with hammer crusher wear parts to use for a long time, high production efficiency, a small investment of late.
Crushing 800 tons of material per hour the Twenty20 1980s, large jaw crusher feed size has reached about 1800 mm. Jaw crusher used two elbows and single bracket plate. The former moving jaw work only for simple swing arc, it is also known as simple swing jaw crusher; latter while swinging in an arc up and down movement, it is also known as complex swing jaw crusher. The jaw crusher is widely used in mining, smelting, building material, highway, railway, water conservancy and stone industry and many other sectors, crushing various materials with compressive strength less than 320 MPa.
Working Principle:
The structure of the jaw crusher frame, eccentric shaft, big pulley, flywheel, moving jaw, side guard plate, toggle plate, toggle plate back seat, adjust gap screw, reset spring, fixed jaw plate and activities jaw , which brackets also play a role as insurance.
This series of jaw crusher crushing way for music moving extrusion type, motor-driven belt and pulley, through the eccentric shaft to make the movable jaw up and down movement, when the movable jaw rises larger angle between toggle plate and moving jaw, thus promoting the moving jaw plate close to the fixed jaw plate, at the same time the material is squeezed, rubbing, grinding, such as multiple broken; When the movable jaw down, the angle between toggle plate and moving jaw smaller, movable jaw plate trolley leave spring fixed jaw plate, the crushed material is discharged from the crushing chamber mouth With the motor continuously rotating broken motor Hubei periodically crushed and nesting to achieve mass production.
Performance Characteristics:
1, Crushing chamber depth and no dead zone, increased capacity and output feed;
2, Broken than large, uniform particle size;
3, Gasketed discharge opening adjustment device, reliable and convenient adjustment range, to increase the flexibility of the device;
4, Lubrication system is safe and reliable, easy to replace parts, maintenance workload is small;
5, Simple structure, reliable operation, low operating costs;
6, Equipment energy-saving: stand-alone energy-saving 15% to 30%, saving more than doubled;
7, Nesting population adjustment range, to meet the requirements of different users;
8, Low noise, less dust.
