Micro Mill Carbon
Micro Mill Carbon Introduction:
Micro mill carbon for barite, calcite, feldspar, talc, marble, limestone, ceramic, glass, Mohs hardness not more than seven, non-flammable and explosive mining humidity below 6%,280 kinds of materials in the stone industry, building materials, metallurgy and other industries powder processing, product size is in the range of 100-425 mesh arbitrary regulation.
Micro Mill Carbon Care and Maintenance:
1, Mill in the use of the process, there should be a fixed staff responsible for the care, the operator must have a certain level of technology. Mill before installing the operating personnel must carry out the necessary technical training to understand the principle of the mill performance, familiar with operating procedures.
2, Mill normal, should develop equipment "equipment maintenance, safe operation of the system" can ensure the mill long-term safe operation, and at the same time have the necessary repair tools and grease and accessories.
3, Mill use for some time, should be carried out maintenance, overhaul to replace wearing parts of the roller mill ring blade processing, grinding roller device in use before connecting bolt nut should be carefully examined to see if there is a loosening , to add a little grease.
4, The roller device use time more than 500 hours or so to replace the roller of each roller comprising rolling bearings must be cleaned, damaged parts should be replaced, refueling tool can be used to manually add the oil pump and grease gun.
Micro Mill Carbon Application:
Micro mill carbon is widely applicable to the barite, calcite, feldspar, talc, marble, limestone, dolomite, fluorite, lime, activated clay, activated carbon, bentonite, kaolin, cement, phosphate rock, gypsum, glassinsulation materials Mohs hardness of not more than 7 and humidity below 6% of non-flammable mineral, chemical, construction and other industries more than 300 kinds of materials for high fine powder processing.
Micro Mill Carbon Working Principle:
Large block of raw materials to the required feed size jaw crusher crushing machine materials transported to storage silos, and then by the electromagnetic vibrating feeder evenly sent to the host of grinding cavity, shovel bucket elevatorknife and grinding roller with the transfer process, the material is scooped up throwing feeding grinding roller between the roller ring, the formation of the litter layer, the material between the roller and grinding ring grinding, and thus achieve pulverizing purpose. The powder after grinding by the fan airflow into the analysis machine for powder fineness requirements fine powder with the air flow through the pipe into the large cyclone collector, collected separately, then unloader discharge is the finished powder return air duct airflow from the upper end of the large cyclone collector inhalation blower. The powder will be undesirable leaves thrown to the outer wall and the air flow from the coarse sub due to the role of self-gravity into the grinding chamber for regrinding. The entire airflow system of the machine is closed loop, and is in the positive and negative pressure state where the circulating flow.
Liming Micro Mill Carbon:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy micro mill carbon manufacturer capable of producing all types of micro mill carbon, good quality and reasonable prices. Liming Heavy Industry production of micro mill carbon is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized micro mill carbon is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of micro mill carbon, please contact us directly. We aim to provide you with the best micro mill carbon and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
