Concrete Recycling Crusher
Author:liming Post Date:2012-11-21
Concrete Recycling Crusher
Introduction to Concrete Recycling Crusher:
The concrete recycling crusher sizes of raw materials, broken into small pieces of uniform particles, concrete recycling crusher both and beneficiation equipment, sand and gravel equipment for, also can be used alone. The concrete recycling crusher also produce the cornerstone of the road, railway ballast stone and construction sand and gravel aggregate. The Jaw Crusher divided into coarse crushing the concrete recycling crusher and crushing concrete recycling crusher, which is commonly referred to as PE series concrete recycling crusher and PEX series concrete recycling crusher. Liming Heavy production of concrete recycling crusher products, has broken than large, the product uniform particle size, simple structure, reliable operation, easy maintenance, low operation cost characteristics.
Concrete Recycling Crusher Working Principle:
The main structure of the concrete recycling crusher frame, eccentric shaft, big pulley, flywheel, side guard plate, toggle plate, toggle plate back seat, adjust gap screw, reset spring, fixed jaw plate and moving jaw.
Work when the motor drive belt and pulley, through the eccentric shaft to make the movable jaw up and down movement, when the movable jaw rises larger angle between toggle plate and moving jaw, thus promoting the movable jaw plate close to the fixed jaw plate at the same time the material pushed pressure, rubbing, grinding, such as multiple broken; When the movable jaw down, the angle between toggle plate and moving jaw smaller, movable jaw plate lever spring to leave the fixed jaw plate material has been crushed in the gravity Next, after the spout of the lower portion of the jaw cavity free unloading. Thus jaw crusher work is intermittent, crushing and unloading process in the jaw cavity alternately. With the motor continuously rotating crusher mobile jaw crushing and nesting periodicity, and mass production.
The Concrete Recycling Crusher Fault Repair:
1, The host suddenly shutdown (commonly known as: stuffy car).
Reasons: 1) the discharge opening clogged, causing wholehearted blocking material; 2) V-belt drive sheave rotation too loose, causing the belt slipping; 3) tight set of eccentric shaft sleeve is loose, causing no clearance on both sides of the rack bearing , the eccentric shaft card dead, can not rotate; 4) workplace voltage is too low, the host encounter aniseed, weakness broken; 5) bearing damage.
Remedy: 1) Clear discharge opening obstructions to ensure smooth material; 2) V-belt tightening or replacement; 3) re-install or replace the adapter sleeve; 4) adjusting the voltage of the positive workplace to make it comply with the host operating voltage requirements; 5) replace the bearings.
2, Host sheaves moving jaw functioning normally, but broken cease work.
Reasons: 1) tension spring break; 2) Trolley fracture; 3) bracket off or broken.
Remedy: 1) replace the tension spring; 2) replace the trolley; 3) re-install or replace the bracket.
3, Production to reach factory standards.
Reasons: 1) the broken material hardness or toughness over the use of the limits prescribed by the manual; 2) motor wiring position is reversed, host open anti-vehicle (moving jaw clockwise rotation), or motor delta connection connected as a star connection; 3) the discharge opening is less than the specified limit; 4) jaw displacement, addendum addendum relative; 5) low voltage work site; 6) movable jaw and bearing wear, the gap is too large, the bearing outer ring occurred relatively rotation.
Remedy: 1) replace or increase crusher; 2) replacement motor wiring; 3) to the instructions provided for nominal discharge opening and increased crusher for crushing the nesting population adjustment; 4) Check the teeth plate pitch dimensions, such as shall be sub-standard replacement jaw, adjusting the relative position of the fixed jaw plate and movable jaw plate the addendum tooth root, fixed clamping to prevent displacement; 5) increase the voltage to meet host weight set out requirements; 6) the replacement of the bearings or moving jaw.
4, Have beat or percussion work activities with fixed jaw plate.
Reasons: 1) jaw fastening bolts loose or falling; 2) the discharge opening is too small, the bottom of the mutual impact of the two jaws.
Remedy: 1) tight set or filled and bolts; 2) is adjusted discharge opening, ensure the correct gap of two jaw.
Concrete Recycling Crusher Operating Environment:
In the process of huge stones are broken into small stones, the first crusher is usually referred to as a "master" crusher. The longest history, but also the most solid crusher jaw crusher. Jaw crusher feeding the material from the top of the entrance into the crushing chamber containing jaw teeth. Jaw teeth with great force the material to the top of the wall will be broken into smaller stones. Support the jaw movement is an eccentric shaft, this axis throughout the body architecture. The eccentric motion is usually generated by a flywheel fixed on the shaft ends. Flywheel and often eccentric support bearing spherical roller bearings, bearing extremely harsh working environment. The bearings must withstand tremendous impact load, abrasive sewage and high temperature. Although this work is extremely harsh environment, jaw crusher still need to work very reliably.
Liming Concrete Recycling Crusher:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy concrete recycling crusher manufacturer capable of producing all types of concrete recycling crusher, good quality and reasonable prices. Liming Heavy Industry production of concrete recycling crusher is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized concrete recycling crusher is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of concrete recycling crusher, please contact us directly. We aim to provide you with the best concrete recycling crusher and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
