Jual Jaw Crusher Machine

Author:liming   Post Date:2013-11-21


Jual Jaw Crusher Machine

Jual Jaw Crusher Machine Working Principle:

Motor through the belt so that the rotation of the eccentric shaft, the up and down movement of the vertical rod that is, when the vertical link up, driven by two brackets gradually stretched flat bracket to force the movable jaw to the fixed jaw forward, crushing chamber (iecomposed of fixed jaw plate and moving jaw space) in the ore being squeezed, splitting, fold flexor and broken. Vertical link-down movement, toggle plate and movable jaw plate, by the force of the springs and tie rods to the back at the port of discharge increase, the ore is broken thus discharged. Visible jual jaw crusher machine is intermittently broken ore. The eccentric shaft of a turn each half cycle for crushing and subsequent half cycle for the row of ore. So it is compared with other continuous crushing machinery, power consumption greater mechanical efficiency is lower.

Production of Less Than Factory Standard:

Jual jaw crusher machine production to reach the factory standard exclusion method:

1, replace or increase the crusher;

2, replacement motor wiring;

3, nesting population adjustment to the instructions provided for nominal discharge opening and increased crusher used for crushing.

Jual Jaw Crusher Machine Performance Characteristics:

1, Crushing chamber depth and no dead zone, increased capacity and output feed.

2, Its crushing ratio, uniform particle size.

3, Gasket discharge opening adjustment device, reliable and convenient adjustment range, and increase the flexibility of the device.

4, The lubrication system is safe and reliable, easy to replace parts, maintenance workload is small.

5, Simple structure, reliable operation, low operating costs.

6, Energy-saving equipment: stand-alone energy-saving 15% to 30%, saving more than doubled.

7, The nesting population adjustment range, to meet the requirements of different users.

8, Low noise, less dust.

Jual Jaw Crusher Machine Species:

The jual jaw crusher machine common two ways: on the move type under acting. On the dynamic type jual jaw crusher machine constant width of the port of discharge, the work is often clogged, affecting the normal work, so now been eliminated. Under dynamic type jual jaw crusher machine concentrator. It is constituted by the following main components: a fixed jaw and the front wall of the rack, suspended on the shaft of the movable jaw, the eccentric shaft, the vertical rod, the toggle plate, the drive flywheel. Two jaw board the liner, with a spring lever, elbow board seat, adjust the block.

Liming Jual Jaw Crusher Machine:

Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy jual jaw crusher machine manufacturer capable of producing all types of jual jaw crusher machine, good quality and reasonable prices. Liming Heavy Industry production of jual jaw crusher machine is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized jual jaw crusher machine is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.

If you need any help of jual jaw crusher machine, please contact us directly. We aim to provide you with the best jual jaw crusher machine and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
