Windshield Crusher
Author:liming Post Date:2013-1-19
Windshield Crusher
Windshield Crusher Introduction:
Windshield crusher (referred to as the back-breaking) and hammer crusher belong to impact the role of the main machine to crushing brittle materials, also called windshield crusher. The series equipment suitable for the size of not more than 500 mm, the compressive strength of not more than 350MPa of various materials (granite, limestone, concrete, etc.) coarse, medium, fine, widely used in a variety of ore crushing, railway, highway, energy, cement, chemical, construction and other industries. Its nesting stone size can be adjusted, crushing specifications diversification, great crushing ratio, high crushing efficiency, easy maintenance characteristics of the finished products are cubic, is ideal senior road surface and hydropower construction aggregate processing equipment.
Windshield Crusher Technical Characteristics:
1, windshield crusher multi-cavity uniform crusher suitable for crushing hard rock;
2, are the entire board structure was small particle size and the cube-shaped nesting, without internal cracks;
3, low feed port for easy production line layout and increase the size of the feed;
4, full hydraulic opening, ease of maintenance and replacement of wearing parts;
5, windshield crusher board hammer new wear-resistant materials, longer life counterattack plate and liner.
Performance Characteristics:
1.Crusher can effectively deal with a large amount of material moisture, prevent crusher clogging. Processing materials excessive moisture, windshield crusher feed chute and counterattack board can be equipped with a heating device to prevent the adhesion of the material.
2. The windshield crusher applies to both the soft materials and suitable for very large hard materials. The plate hammer Crusher mechanical clamping structure is firmly fixed on the rotor, when the great moment of inertia with the rotor rotates. Relative to the hammer crusher (hammer was hanging), windshield crusher rotor has greater momentum adapt crushing hard materials, while the energy consumption is lower.
3. windshield crusher can be convenient and flexible adjustment of feed size, wide range of adjustment. Impact Crusher through a variety of ways to adjust the particle size, such as the regulation of the rotor speed, adjust the counter plate and the grinding chamber gap. The gap adjustment can be adjusted by a mechanical or hydraulic.
4. Crusher wearing parts wear than small hammer crusher, high utilization of metal. Counterattack crusher plate hammer wear only Looking materials side. Normal rotor speed, feed plate hammer will fall to the surface (of attack), the plate hammer back and sides are not to be worn. Even Looking material side wear very little. And the bottom of the grinding rod is also very easy to replace. windshield crusher board hammer metal utilization rate can be as high as 45% -48%. Hammer crusher hammer was hanging, wear and tear occurs in the upper, front, rear and side, relative to the plate hammer, hammer wear more serious hammer metal utilization ratio is only 25%, and the rotor body may be subjected to wear.
5. Crusher spare parts easy to replace, and a corresponding reduction in maintenance costs. Just one shift only install six board Hammer Crusher rotor can easily board hammer replacement, replacement of a board hammer time. The bottom of the grinding chamber grinding rod replacement requires only tens of minutes can greatly reduce the time and cost of repair and maintenance.
Use and Maintenance:
In normal use, the operator according to the hammer plate wear and the crushed product size to adjust the radial gap between the impingement plate and the grinding plate and the hammer plate. With the wear plate hammer crusher product size will gradually thicken. At present, our company mainly manufacturing plate hammer and the impact of high manganese steel plate.
Windshield crusher bearing installed in strict accordance with the method prescribed by the manufacturer of the production of bearings, check and adjust the bearing clearance and lubrication device and the timely replacement of seals, bearings to ensure the normal work.
Windshield Crusher Working Principle:
Windshield crusher counterattack crusher is a use of impact energy to break material crushing machinery.When the unit is operating, the motor driven rotor high-speed rotating materials into the active area of the plate hammer, windshield crusher plate hammer on the rotor, and later was thrown counterattack device again broken, then from counterattack linerbounced back to the the board hammer district re-broken, and this process is repeated, the material descending into one, two, three, fight back cavity repeated broken until the materials are crushed to the required size of the discharge port. Adjust the gap between the frame and the rotor counterattack up to change the purpose of material discharging size and material shape.
Liming Windshield Crusher:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy windshield crusher manufacturer capable of producing all types of windshield crusher, good quality and reasonable prices. Liming Heavy Industry production of windshield crusher is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized windshield crusher is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of windshield crusher, please contact us directly. We aim to provide you with the best windshield crusher and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
